一种构造设计结构矩阵的简化方法

详细信息

A Practical Method for Constructing Design Structure Matrix

School of Economics and Management, Beijing University of Aeronautics and Astro nautics, Beijing 100191, China

摘要: 设计结构矩阵是一种对复杂产品设计流程优化的有效工具。任务间耦合强度的确定是构造设计结构矩阵的关键,它对设计结构矩阵的规划有着重要意义。文章采用模糊层次分析法构造敏感性和可变性的模糊一致判断矩阵,并通过一定算法映射到设计结构矩阵中任务间的耦合强度,最后为二级减速器设计结构矩阵中耦合强度的确定给出了相应的算例。与其它方法相比,此方法更具普遍性和易操作性。
- 设计结构矩阵 /
- 耦合强度 /
- 模糊层次分析法
Abstract: Design structure matrix is an effective tool for design process optimization of complex product. The fixation of coupling intensity among tasks is the key to co nstruct design structure matrix (DSM), which plays a good role in the layout of DSM. This paper uses fuzzy analytic hierarchy process (FAHP) to construct sensit ive and variable fuzzy consistent judgment matrix (FCJM), and changes them into coupling intensity in DSM by a special algorithm. At last, the fixation of coupl ing intensity in second-hierarchy decelerating machine is given as the example to apply FAHP to fixation of coupling intensity in DSM. Compared with other meth ods, it has strong applicability and is easy to operate.
- design structure matrix /
- coupling intensity /
- fuzzy analytic hierarchy process

[1]	Steward D V. The Design Structure: A Method for Managing the Design of Complex System[J]. IEEE Trans on Engineering Management, 1981, (8): 71-74.
[2]	Shi-Jie, Chena, Li Linb. Decomposition of Interdependent Task Group for Concurrent Engineering[J]. Computers & Industrial Engineering, 2003, 44: 435-459.
[3]	贡智兵, 李东波, 于敏健. 基于设计结构矩阵变更的设计过程动态规划[J]. 计算机集成制造系统,2007, 13(3).
[4]	张汉鹏, 邱菀华. 基于DSM的产品开发进度规划模型及其应用[J]. 北京航空航天大学学报(社会科学版), 2007, 20(1).
[5]	张吉军. 模糊层次分析法(FAHP)[J]. 模糊系统与数学, 2000, 14(2).
[6]	岳超源. 决策理论与方法[M]. 北京:科学出版社, 2002.
[7]	Krishnan V, Eppinger S D, Whitney D E. A Model-Based Framework to Ov erlap Product Development Activities[J]. Management Science, 1997, 43(3): 437 -451.
