Sensitivity analysis and optimization design of high stealth flying wing layout airfoil
-
摘要:
高隐身飞翼布局必须满足宽频段隐身设计要求，传统气动外形隐身设计主要面向高频光学区，针对谐振区翼型气动外形隐身设计的研究较少，无法为飞翼布局气动外形宽频隐身设计提供有效的指导。开展飞翼布局翼型宽频隐身设计研究，利用基本效应法开展了不同频段下翼型外形参数敏感性研究，发现高、低频段隐身设计与气动设计要求对翼型气动外形敏感性区域各不相同，不同频段隐身设计存在复杂的矛盾关系。在此基础上，提出飞翼布局宽频隐身设计模型，以NACA65,3-018翼型为基础开展考虑宽频隐身的气动优化设计。结果表明：所提模型可以提高飞翼布局翼型气动性能，同时实现宽频段高隐身特性。
Abstract:High-stealth flying wing layouts must meet the requirements of wideband stealth design. Traditional aerodynamic shape stealth design mainly targets the high-frequency optical range, and there is relatively little research on aerodynamic shape stealth design for wing profiles in the resonance range, making it incapable of providing effective guidance for wideband stealth design of flying wing aerodynamic shapes. To address these issues, research on wideband stealth design of wing layouts was conducted. Firstly, the basic effects method was used to study the sensitivity of wing profile parameters in different frequency bands, and it was found that the requirements for low-frequency stealth design and aerodynamic design have different sensitivity areas to the aerodynamic shape of the airfoil, and there are complex contradictions in stealth design in different frequency bands. This is the basis for a wideband stealth design model for wing layout, and NACA65,3-018 airfoils are used for aerodynamic optimization design that takes wideband stealth into account. The results show that the established wideband stealth design model can improve the aerodynamic performance of wing layout airfoils, simultaneously achieving wideband high stealth characteristics.
-
图 2 FEKO与二维矩量法计算结果对比
Figure 2. Results comparison of FEKO and 2D moment method calculations
图 9 单点优化翼型RCS特性对比
Figure 9. Comparison of RCS performance of airfoils subjected to single-point optimization
图 11 多点优化翼型RCS特性对比
Figure 11. Comparison of RCS performance of airfoils subjected to multi-point optimization
图 12 气动隐身优化翼型外形对比
Figure 12. Comparison of aerodynamic and stealth optimized airfoil shapes
图 14 气动隐身优化翼型RCS特性对比
Figure 14. Comparison of RCS performance of airfoils from aerodynamio-stealth optimization
表 1 优化翼型特性
Table 1. Performance of optimized airfoil
外形 RCS/m f=300 MHz f=9 GHz NACA65,3-018 0.0449 0.0596 Opt_300 MHz 9 GHz 0.0402 0.0040
下载: 导出CSV
表 2 优化翼型特性
Table 2. Performance of optimized airfoil
外形 Cd Cm RCS/m f=300 MHz f=9 GHz NACA65,3-018 0.01141 −0.010 0.0449 0.0596 Opt_Aero/Stealth 0.00934 0.0301 0.0401 0.0086
下载: 导出CSV
-
[1] ROMAN D, ALLEN J, LIEBECK R. Aerodynamic design challenges of the Blended-Wing-Body subsonic transport[C]//Proceedings of the 18th Applied Aerodynamics Conference. Reston: AIAA, 2000. [2] ROMAN D, GILMORE R, WAKAYAMA S. Aerodynamics of high-subsonic blended-wing-body configurations[C]//Proceedings of the 41st Aerospace Sciences Meeting and Exhibit. Reston: AIAA, 2003. [3] LIEBECK R H. Design of the blended wing body subsonic transport[J]. Journal of Aircraft, 2004, 41(1): 10-25. [4] KROO I. Innovations in aeronautics[C]//Proceedings of the 42nd AIAA Aerospace Sciences Meeting and Exhibit. Reston: AIAA, 2004. [5] 张伟, 赵轲, 夏露, 等. 飞翼布局翼型系列设计进展[J]. 空气动力学学报, 2021, 39(6): 37-52.ZHANG W, ZHAO K, XIA L, et al. A multi-disciplinary global/local optimization method for flying-wing airfoils design[J]. Acta Aerodynamica Sinica, 2021, 39(6): 37-52(in Chinese). [6] ZHANG W, GAO Z H, WANG C, et al. The niching-based adaptive space reconstruction method for airfoil aerodynamic/stealth design[J]. Structural and Multidisciplinary Optimization, 2023, 66(7): 159. [7] 张彬乾, 罗烈, 陈真利, 等. 飞翼布局隐身翼型优化设计[J]. 航空学报, 2014, 35(4): 957-967.ZHANG B Q, LUO L, CHEN Z L, et al. On stealth airfoil optimization design for flying wing configuration[J]. Acta Aeronautica et Astronautica Sinica, 2014, 35(4): 957-967(in Chinese). [8] TAJ Z U D, BILAL A, AWAIS M, et al. Design exploration and optimization of aerodynamics and radar cross section for a fighter aircraft[J]. Aerospace Science and Technology, 2023, 133: 108114. [9] ZHANG W, GAO Z H, ZHOU L, et al. Research on multimodality in aerodynamic/stealth airfoil design optimization[C]//Proceedings of the 12th International Conference on Mechanical and Aerospace Engineering. Piscataway: IEEE Press, 2021: 384-393. [10] VINH H, DWYER H, VAN DAM C. Finite-difference algorithms for the time-domain Maxwell's equations-A numerical approach to RCS analysis[C]//Proceedings of the 23rd Plasmadynamics and Lasers Conference. Reston: AIAA, 1992. [11] BONDESON A, YANG Y, WEINERFELT P. Shape optimization for radar cross sections by a gradient method[J]. International Journal For Numerical Methods In Engineering, 2004, 61(5): 687-715. [12] 陈曦, 白俊强, 李权. 某飞翼布局隐身飞行器的翼型优化[J]. 航空计算技术, 2013, 43(6): 46-49.CHEN X, BAI J Q, LI Q. Airfoil optimization of a stealth flying wind aerial vehicle[J]. Aeronautical Computing Technique, 2013, 43(6): 46-49(in Chinese). [13] 周琳. 基于全局/梯度耦合的低可探测布局气动隐身设计研究[D]. 西安: 西北工业大学, 2022.ZHOU L. Research on global/local based aerodynamic/stealth optimization of low observable aircrafts[D]. Xi’an: Northwestern Polytechnical University, 2022(in Chinese). [14] SALTELLI A, ANNONI P, AZZINI I, et al. Variance based sensitivity analysis of model output. Design and estimator for the total sensitivity index[J]. Computer Physics Communications, 2010, 181(2): 259-270. [15] 张伟, 高正红, 周琳, 等. 基于代理模型全局优化的自适应参数化方法[J]. 航空学报, 2020, 41(10): 160-171.ZHANG W, GAO Z H, ZHOU L, et al. Adaptive parameterization method for surrogate-based global optimization[J]. Acta Aeronautica et Astronautica Sinica, 2020, 41(10): 160-171(in Chinese). [16] MORRIS M D. Factorial sampling plans for preliminary computational experiments[J]. Technometrics, 1991, 33(2): 161-174. [17] KNOTT E F. A progression of high-frequency RCS prediction techniques[J]. Proceedings of the IEEE, 1985, 73(2): 252-264. [18] 桑建华. 飞行器隐身技术[M]. 北京: 航空工业出版社, 2013.SANG J H. Low-observable technologies of aircraft[M]. Beijing: Aviation Industry Press, 2013(in Chinese). [19] SEARS W. Flying-wing airplanes——The XB-35/YB-49 program [C]//Proceedings of the Symposium. Reston: AIAA, 1980. [20] LIEBECK R. Design of the blended-wing-body subsonic transport[C]//Proceedings of the 40th AIAA Aerospace Sciences Meeting & Exhibit. Reston: AIAA, 2002. [21] BARTELS R E, RUMSEY C L, BIEDRON R T. CFL3D version 6.4-general usage and aeroelastic analysis[EB/OL]. (2022-08-12)[2024-01-15]. https://nasa.github.io/CFL3D/. [22] PRAUTZSCH H, BOEHM W, PALUSZNY M. Bézier and B-spline techniques[M]. Berlin: Springer, 2002. -
