Multidisciplinary coupled dynamics modeling of electro-mechanical actuator considering nonlinear clearances in multiple stages
-
摘要:
由于设计装配不确定性，电动舵机传动系统多环节存在间隙等非线性因素，严重影响工作品质，需建立非线性动力学模型。同时，其涵盖伺服控制、电机传动、减速机构、结构弹性等多学科，建模极具挑战。本研究以典型的滚珠丝杠式电动舵机为研究对象，考虑舵机传动元件的弹性刚度及齿轮副、支撑轴承和拨叉副处的间隙非线性，对电机动力学、伺服控制器进行精细化建模，建立了一种能考虑多环节间隙非线性的电动舵机系统高保真多学科动力学模型，并开展了电动舵机系统性能仿真分析。仿真结果与舵机-舵面系统地面振动试验结果进行了对比。结果表明：所建立的电动舵机多学科耦合动力学模型能够反映机构不同环节间隙非线性的影响和影响程度，仿真和试验结果吻合较好，最大误差小于10%。研究结果为航空航天复杂电动伺服系统的数字孪生研究奠定了基础。
Abstract:Due to uncertainties in the design and assembly process, nonlinear factors such as clearances often exist in multiple sectors of the aerospace electro-mechanical actuator transmission system, significantly affecting the working quality of the electro-mechanical actuator. Therefore, it is essential to accurately establish a nonlinear dynamic model for the electro-mechanical actuator accurately. Moreover, electro-mechanical actuators involve multiple disciplines such as servo control, motor transmission, reduction mechanism, structural elasticity, etc., making the modeling process highly challenging. The research object in this paper is a standard ball screw-type electro-mechanical actuator. Considering the elastic stiffness of actuator transmission components and the nonlinearity of clearances at gear pairs, supporting bearings, and fork pairs, the motor dynamics and servo controllers are finely modeled. The electro-mechanical actuator system is represented by a high-fidelity multidisciplinary dynamic model that can account for nonlinearities in different sector clearances. Furthermore, simulation analysis of the electro-mechanical actuator system performance is conducted. The simulation results are compared with ground vibration test results of the actuator-rudder system. The results indicate that the multidisciplinary coupled dynamic model of the electro-mechanical actuator established in this paper can reflect the influence and degree of influence of the clearances in different parts of the mechanism. The simulation and experimental results are in good agreement, with a maximum error of less than 10%. This research lays the foundation for the digital twin study of complex aerospace electric servo systems.
-
图 3 电动舵机机械传动系统动力学模型
Figure 3. Dynamic model of electro-mechanical actuator transmission system
图 4 电动舵机机械传动系统框图模型
Figure 4. Block diagram model of electro-mechanical actuator transmission system
图 5 电动舵机整体机电耦合框图模型
Figure 5. Electromechanical coupling block diagram model of electro-mechanical actuator
图 6 1°阶跃激励下不同舵机仿真模型的结果对比
Figure 6. Comparison of the results of different actuator simulation models under a 1° step excitation
图 7 考虑多环节间隙的电动舵机舵偏角共振频率-共振幅值曲线
Figure 7. Resonance frequency-amplitude curve of rudder angle for electro-mechanical actuator considering various sectors clearances
图 8 考虑多环节间隙的电动舵机舵偏角激励力-共振频率曲线
Figure 8. Excitation force-resonance frequency curve of rudder angle for electro-mechanical actuator considering various sectors clearances
图 9 考虑单环节间隙的电动舵机舵偏角共振频率-共振幅值曲线
Figure 9. Resonance frequency-amplitude curve of rudder angle for electro-mechanical actuator considering single sector clearance
表 1 非线性电动舵机系统各环节间隙设置情况
Table 1. Clearance settings for various sectors in nonlinear electro-mechanical actuator system
工况 齿轮副间隙/rad 轴承间隙/mm 拨叉副间隙/rad 间隙最小组合 0.001 0.001 0.000 2 间隙最大组合 0.01 0.01 0.000 4
下载: 导出CSV
表 2 1°阶跃激励下电动舵机模型舵偏角阶跃响应仿真与试验结果
Table 2. Simulation and experimental results of step response of rudder angle in electro-mechanical actuator model under a 1° step excitation
工况 超调量/% 过渡过程时间/ms 指标 ≤25 ≤40 试验 15.06 16.00 简化模型 0.00 20.43 精细模型 4.40 16.83 间隙最小模型 4.20 16.83 间隙最大模型 6.70 16.45
下载: 导出CSV
表 3 考虑多环节间隙的电动舵机舵偏角共振频率数据
Table 3. Resonance frequency data of rudder angle for electro-mechanical actuator considering various sectors clearances
激励力/N 试验共振频率/Hz 间隙最小组合共振频率/Hz 与试验结果误差/% 间隙最大组合共振频率/Hz 与试验结果误差/% 10 140.8 154.0 9.4 142.4 1.1 20 149.8 156.7 4.6 151.0 0.8 30 154.7 158.3 2.3 155.4 0.5 40 160.0 159.1 2.0 157.7 1.4 50 161.3 159.4 1.2 158.4 1.8
下载: 导出CSV
表 4 不同激励工况下考虑单环节间隙的电动舵机舵偏角共振频率和共振幅值数据
Table 4. Resonance frequency and amplitude data of rudder angle for electro-mechanical actuator considering single sector clearance under various excitation conditions
工况 激励力/N 间隙最小共
振频率/Hz间隙最小共
振幅值/rad间隙最大共
振频率/Hz间隙最大共
振幅值/rad齿轮副
间隙10 160.3 $ 5.589\times {10}^{{-}5} $ 159.9 $ 3.494\times {10}^{{-}5} $ 20 160.3 $ 1.154\times {10}^{{-4}} $ 159.9 $ 9.493\times {10}^{{-}5} $ 30 160.3 $ 1.928\times {10}^{{-4}} $ 160.3 $ 1.525\times {10}^{{-4}} $ 40 160.3 $ 3.685\times {10}^{{-4}} $ 160.3 $ 3.069\times {10}^{{-4}} $ 50 160.3 $ 6.108\times {10}^{{-4}} $ 160.3 $ 5.518\times {10}^{{-4}} $ 轴承
间隙10 159.3 $ 6.438\times {10}^{{-}5} $ 152.1 $ 8.463\times {10}^{{-}5} $ 20 159.7 $ 1.227\times {10}^{{-4}} $ 156.0 $ 1.481\times {10}^{{-4}} $ 30 159.7 $ 2.040\times {10}^{{-4}} $ 158.0 $ 2.478\times {10}^{{-4}} $ 40 160.1 $ 3.856\times {10}^{{-4}} $ 158.9 $ 4.646\times {10}^{{-4}} $ 50 160.3 $ 6.321\times {10}^{{-4}} $ 159.3 $ 7.499\times {10}^{{-4}} $ 拨叉副
间隙10 154.9 $ 7.710\times {10}^{{-}5} $ 149.6 $ 9.128\times {10}^{{-}5} $ 20 157.3 $ 1.408\times {10}^{{-4}} $ 154.9 $ 1.542\times {10}^{{-4}} $ 30 158.4 $ 2.314\times {10}^{{-4}} $ 157.3 $ 2.647\times {10}^{{-4}} $ 40 159.3 $ 4.428\times {10}^{{-4}} $ 158.6 $ 4.937\times {10}^{{-4}} $ 50 159.6 $ 7.020\times {10}^{{-4}} $ 159.1 $ 7.772\times {10}^{{-4}} $
下载: 导出CSV
-
[1] YOO C H, LEE Y C, LEE S Y. A robust controller for an electro-mechanical fin actuator[C]//Proceedings of the 2004 American Control Conference. Piscataway: IEEE Press, 2005, 5: 4010-4015. [2] 黄璐, 文军, 姜杰. 电动舵机系统建模与仿真研究[J]. 自动化与仪器仪表, 2020(12): 237-239.HUANG L, WEN J, JIANG J. Research on modeling and simulation of electric servo system[J]. Automation & Instrumentation, 2020(12): 237-239(in Chinese). [3] KIM S H, TAHK M J. Dynamic stiffness transfer function of an electromechanical actuator using system identification[J]. International Journal of Aeronautical and Space Sciences, 2018, 19(1): 208-216. [4] LU J, WU Z G, YANG C. Active flutter suppression of nonlinear fin-actuator system via inverse system and immersion and invariance method[J]. Chinese Journal of Aeronautics, 2024, 37(4): 343-362. [5] RISTANOVIĆ M, LAZIĆ D, INĐIN I. Experimental validation of improved performances of an electromechanical aerofin control system with a PWM controlled DC motor[J]. FME Transactions, 2006, 34(1): 15-20. [6] ÖZKAN B. Control of an electromechanical control actuation system using a fractional order proportional, integral, and derivative-type controller[J]. IFAC Proceedings Volumes, 2014, 47(3): 4493-4498. [7] 石忠佼, 朱化杰, 赵良玉, 等. 考虑舵机动力学的旋转弹自适应解耦控制[J]. 航空学报, 2022, 43(3): 333-343.SHI Z J, ZHU H J, ZHAO L Y, et al. Adaptive decoupling control for a class of spinning rockets considering actuator dynamics[J]. Acta Aeronautica et Astronautica Sinica, 2022, 43(3): 333-343(in Chinese). [8] 黄健伟, 覃泽龙, 徐新, 等. 基于ESO的无人机舵机系统控制策略研究[J]. 兵器装备工程学报, 2023, 44(7): 257-263.HUANG J W, QIN Z L, XU X, et al. Research on the control strategy of UAV electromechanical actuator system based on ESO[J]. Journal of Ordnance Equipment Engineering, 2023, 44(7): 257-263(in Chinese). [9] 李朋, 高智刚, 周军, 等. 高性能电动舵机系统高保真建模方法研究[J]. 西北工业大学学报, 2018, 36(1): 7-12.LI P, GAO Z G, ZHOU J, et al. High fidelity modeling method of high performance electromechanical actuator[J]. Journal of Northwestern Polytechnical University, 2018, 36(1): 7-12(in Chinese). [10] KAYRAN A, NALCI M O. Aeroservoelastic modeling and analysis of a missile control surface with a nonlinear electromechanical actuator[C]//Proceedings of the AIAA Atmospheric Flight Mechanics Conference. Reston: AIAA, 2014: 2055. [11] 许行之, 高亚奎, 章卫国. 考虑舵机动力学的舵回路系统颤振特性分析[J]. 计算机仿真, 2014, 31(10): 80-85.XU X Z, GAO Y K, ZHANG W G. Flutter characteristics analysis for actuator-fin system with dynamic stiffness[J]. Computer Simulation, 2014, 31(10): 80-85(in Chinese). [12] 张新榃, 吴志刚, 杨超. 考虑舵机动力学的舵系统颤振特性分析[J]. 北京航空航天大学学报, 2011, 37(8): 927-932.ZHANG X T, WU Z G, YANG C. Flutter analysis for rudder considering actuator’s dynamics[J]. Journal of Beijing University of Aeronautics and Astronautics, 2011, 37(8): 927-932(in Chinese). [13] ZHANG X T, WU Z G, YANG C. New flutter-suppression method for a missile fin with an actuator[J]. Journal of Aircraft, 2013, 50(3): 989-994. [14] LAYTON D, GAINES V. F-22 actuator dynamic stiffness (impedance) testing[C]//Proceedings of the 48th AIAA/ASME/ASCE/AHS/ASC Structures, Structural Dynamics, and Materials Conference. Reston: AIAA, 2007: 1792. [15] SANTOS BALLESTEROS H M, DAS NEVES CALVO R, FILHO A A. Dynamic stiffness enhancement of a flight control actuator using control techniques[C]//Proceedings of the 2017 IEEE International Conference on Mechatronics. Piscataway: IEEE, 2017: 260-265. [16] KADIYALA V K, JATOTH R K, POTHALAIAH S. Design and implementation of fractional order PID controller for aerofin control system[C]//Proceedings of the 2009 World Congress on Nature & Biologically Inspired Computing. Piscataway: IEEE Press, 2010: 696-701. [17] 卢晋, 吴志刚, 杨超. 电动舵机模块化建模及动刚度仿真[J]. 北京航空航天大学学报, 2021, 47(4): 765-778.LU J, WU Z G, YANG C. Modular modeling and dynamic stiffness simulation of electromechanical actuator[J]. Journal of Beijing University of Aeronautics and Astronautics, 2021, 47(4): 765-778(in Chinese). [18] 张仁嘉, 吴志刚, 杨超. 电动伺服舵系统动力学建模及颤振分析[J]. 北京航空航天大学学报, 2016, 42(7): 1368-1376.ZHANG R J, WU Z G, YANG C. Dynamic modeling and flutter analysis of a fin-actuator system[J]. Journal of Beijing University of Aeronautics and Astronautics, 2016, 42(7): 1368-1376(in Chinese). [19] 张程, 任浩源, 史泰龙, 等. 含非线性连接的折叠舵全时域多学科耦合分析方法及应用[J]. 航空学报, 2023, 44(增刊2): 729461.ZHANG C, REN H Y, SHI T L, et al. Multidisciplinary full-time coupling methods and applications of folding fin containing non-linear connections[J]. Acta Aeronautica et Astronautica Sinica, 2023, 44(Sup2): 729461. [20] HE H N, TANG H, YU K P, et al. Nonlinear aeroelastic analysis of the folding fin with freeplay under thermal environment[J]. Chinese Journal of Aeronautics, 2020, 33(9): 2357-2371. [21] 王强, 马志赛, 张欣, 等. 基于模态综合法的含间隙折叠舵面动态特性分析[J]. 航空学报, 2020, 41(5): 197-205.WANG Q, MA Z S, ZHANG X, et al. Dynamic characteristic analysis for a folding fin with freeplay nonlinearities based on mode synthesis method[J]. Acta Aeronautica et Astronautica Sinica, 2020, 41(5): 197-205(in Chinese). [22] 白刘月, 吴志刚, 杨超. 含间隙全动舵面的非线性颤振模式及被动抑制方法[J]. 北京航空航天大学学报, 2023, 49(9): 2361-2373.BAI L Y, WU Z G, YANG C. Nonlinear flutter modes and flutter suppression of an all-movable fin with freeplay[J]. Journal of Beijing University of Aeronautics and Astronautics, 2023, 49(9): 2361-2373(in Chinese). [23] 李友年, 陈星阳. 舵机间隙环节对控制系统的影响分析[J]. 航空兵器, 2012, 19(1): 25-27.LI Y N, CHEN X Y. Influence analysis of actuator’s gap on control system[J]. Aero Weaponry, 2012, 19(1): 25-27(in Chinese). [24] 胡江涛, 曹云峰. 滚珠丝杠式电动舵机系统非线性特性分析[J]. 计算机测量与控制, 2018, 26(2): 190-194.HU J T, CAO Y F. Nonlinear factors analysis of EMA with ball screw drive[J]. Computer Measurement & Control, 2018, 26(2): 190-194(in Chinese). [25] 刘鹏, 李怀兵, 杨超凡, 等. 传动间隙引起的电动舵机自振荡现象研究[J]. 微电机, 2022, 55(7): 89-93.LIU P, LI H B, YANG C F, et al. Research on self oscillation of electric actuator caused by transmission clearance[J]. Micromotors, 2022, 55(7): 89-93(in Chinese). [26] 张新华, 黄建, 张兆凯, 等. 大惯量下电动伺服机构非线性特性与控制方法研究[J]. 导航定位与授时, 2017, 4(2): 41-47.ZHANG X H, HUANG J, ZHANG Z K, et al. Research on nonlinear factor characteristics and control method on large inertia electromechanical actuator servo mechanism[J]. Navigation Positioning and Timing, 2017, 4(2): 41-47(in Chinese). -
