Attitude measurement and control method of flexible spacecraft based on distributed installation MSCSG
-
摘要:
为实现挠性航天器姿态振动的高精度测控一体化，提出一种基于分布式安装磁悬浮控制敏感陀螺(MSCSG)和径向基函数(RBF)神经网络的挠性航天器姿态振动测控一体化方法。建立挠性附件上分布式安装MSCSG的航天器动力学模型，分析MSCSG对挠性附件振动测量和控制的机理；在此基础上，设计神经网络鲁棒自适应状态反馈控制器，通过神经网络对分布式安装MSCSG带来的系统非线性项及外部扰动进行逼近，实现MSCSG输出控制力矩抑制挠性附件低频振动，同时，对挠性附件形变进行测量。刚体上安装的MSCSG群同时实现航天器姿态的测量与控制。仿真结果表明：所提方法相较于传统基于模态观测器的自适应控制方法，姿态控制精度及振动抑制效果均得到大幅提升。
Abstract:In order to realize the integration of high-precision measurement and control of attitude vibration of a flexure spacecraft, an integrated method of attitude vibration measurement and control of a flexible spacecraft based on the distributed mounting of a magnetically suspended control sensitive gyroscope (MSCSG) and a radial basis function (RBF) neural network is proposed. Firstly, a spacecraft dynamics model with distributed mounted MSCSG on the flexible attachment is established, and the mechanism of vibration measurement and control of the flexible attachment by MSCSG is analyzed. Based on this, a neural network robust adaptive state feedback controller is designed, and the control torque output from MSCSG is realized suppression of low-frequency vibration of the flexible attachment while also measuring the deformation of the flexible attachment. The neural network approximates the nonlinear terms of the system and external perturbations brought about by distributed mounted MSCSG. The MSCSG cluster installed on the rigid body simultaneously realizes the measurement and control of spacecraft attitude. Simulation results show that the attitude control accuracy and vibration suppression effect of the proposed method are greatly improved compared with the traditional adaptive control method based on a modal observer.
-
图 2 4角安装MSCSG的挠性航天器模型
Figure 2. Flexible spacecraft model with MSCSG mounted at the four corners
图 8 加入模态控制的挠性附件前4阶模态
Figure 8. The first four modes of the flexible attachment with modal control
图 9 新方法加入模态控制的航天器姿态
Figure 9. Spacecraft attitude controlled by new method with modal control
图 10 新方法加入模态控制的挠性附件前4阶模态
Figure 10. The first four modes of the flexible attachment controlled by new method with modal control
图 12 挠性附件上4个MSCSG转子偏转角
Figure 12. Four MSCSG rotor deflection angles on flexible attachment
图 13 挠性附件上4个MSCSG处Z轴弹性转角及其测量值
Figure 13. Z-axis elastic angles of rotation at 4 MSCSGs on the flexible attachment and their measured values
图 14 挠性附件上4个MSCSG处Z轴弹性转角测量误差
Figure 14. Measuring errors of Z-axis elastic angles of rotation at 4 MSCSGs on the flexible attachment
表 1 仿真系统参数
Table 1. Simulation system parameters
转子X轴转动
惯量/(kg·m2)转子Y轴转动
惯量/(kg·m2)转子Z轴转动
惯量/(kg·m2)挠性附件上转子
转速/(r·min−1)刚体上转子
转速/(r·min−1)转子
质量/kgζ μ ρ 0.0097 0.0097 0.0166 1000 8000 8.95 0.5 0.2 0.35
下载: 导出CSV
-
[1] 宋晓娟, 李雪松, 何晓东, 等. 挠性充液航天器复合自适应姿态机动控制[J]. 空间控制技术与应用, 2023, 49(1): 11-20.SONG X J, LI X S, HE X D, et al. Hybrid adaptive attitude maneuver control for flexible liquid-filled spacecraft[J]. Aerospace Control and Application, 2023, 49(1): 11-20(in Chinese). [2] LI W P, LUO B, HUANG H. Active vibration control of flexible joint manipulator using input shaping and adaptive parameter auto disturbance rejection controller[J]. Journal of Sound and Vibration, 2016, 363: 97-125. [3] JIA S Y, SHAN J J. Vibration control of gyroelastic spacecraft using input shaping and angular momentum devices[J]. Acta Astronautica, 2019, 159: 397-409. [4] GAO J S, DENG L W, SONG S M. Fractional order nonsingular terminal sliding mode control for flexible spacecraft attitude tracking[J]. Instrumentation, 2016(1): 21-29. [5] ZHOU C B, ZHOU D. Robust dynamic surface sliding mode control for attitude tracking of flexible spacecraft with an extended state observer[J]. Proceedings of the Institution of Mechanical Engineers, Part G: Journal of Aerospace Engineering, 2017, 231(3): 533-547. [6] 管萍, 罗宗樾, 戈新生. 基于RBF神经网络的挠性航天器分数阶滑模姿态控制[J]. 飞行力学, 2021, 39(6): 68-74.GUAN P, LUO Z Y, GE X S. Fractional order sliding mode attitude control of flexible spacecraft based on RBF neural network[J]. Flight Dynamics, 2021, 39(6): 68-74(in Chinese). [7] 姜野, 胡庆雷, 马广富. 控制输入饱和的挠性航天器姿态机动智能鲁棒控制[J]. 宇航学报, 2009, 30(1): 188-192.JIANG Y, HU Q L, MA G F. Intelligent adaptive variable structure attitude maneuvering control for flexible spacecraft with actuator saturation[J]. Journal of Astronautics, 2009, 30(1): 188-192(in Chinese). [8] 余臻. 挠性航天器姿态机动与主动抑振控制研究[D]. 南京: 南京理工大学, 2017.YU Z. On attitude maneuver control and active vibration suppression of flexible spacecraft[D]. Nanjing: Nanjing University of Science and Technology, 2017(in Chinese). [9] 胡庆雷, 刘亚秋, 马广富. 挠性航天器姿态机动的变结构主动振动抑制[J]. 控制理论与应用, 2007, 24(3): 329-336.HU Q L, LIU Y Q, MA G F. Active vibration suppression in flexible spacecraft with mismatched uncertainty via variable structure control[J]. Control Theory & Applications, 2007, 24(3): 329-336(in Chinese). [10] HU Q L, MA G F. Vibration control of flexible spacecraft actuated by piezoceramics via variable structure strategy[J]. Journal of Harbin Institute of Technology (New Series), 2007, 14(5): 604-608. [11] 马广富, 胡庆雷. 挠性航天器姿态机动的主动振动控制[J]. 哈尔滨工程大学学报, 2005, 26(5): 603-607.MA G F, HU Q L. Active vibration control of flexible spacecraft during attitude maneuver[J]. Journal of Harbin Engineering University, 2005, 26(5): 603-607(in Chinese). [12] SHAHRAVI M, AZIMI M. A comparative study for collocated and non-collocated sensor/actuator placement in vibration control of a maneuvering flexible satellite[J]. Proceedings of the Institution of Mechanical Engineers, Part C: Journal of Mechanical Engineering Science, 2015, 229(8): 1415-1424. [13] GAUDENZI P, GIARDA D, MORGANTI F, et al. Active microvibration control of an optical payload installed on the ARTEMIS spacecraft[J]. Journal of Intelligent Material Systems and Structures, 1998, 9(9): 740-748. [14] DAMAREN C J, D’ELEUTERIO G M T. Optimal control of large space structures using distributed gyricity[J]. Journal of Guidance, Control, and Dynamics, 1989, 12(5): 723-731. [15] DAMAREN C J, D’ELEUTERIO G M T. Controllability and observability of gyroelastic vehicles[J]. Journal of Guidance, Control, and Dynamics, 1991, 14(5): 886-894. [16] HU Q, JIA Y H, XU S J. Simple adaptive control for vibration suppression of space structures using control moment gyroscopes as actuators[C]//Proceedings of the AIAA Guidance, Navigation, and Control Conference. Reston: AIAA, 2013: 4871. [17] HU Q, ZHANG J R. Attitude control and vibration suppression for flexible spacecraft using control moment gyroscopes[J]. Journal of Aerospace Engineering, 2016, 29: 04015027. [18] HU Q, GUO C D, ZHANG J. Singularity and steering logic for control moment gyros on flexible space structures[J]. Acta Astronautica, 2017, 137: 261-273. [19] GUO J T, GENG Y H, WU B L, et al. Vibration suppression of flexible spacecraft during attitude maneuver using CMGs[J]. Aerospace Science and Technology, 2018, 72: 183-192. [20] 李磊, 任元, 陈晓岑, 等. 基于ADRC和RBF神经网络的MSCSG控制系统设计[J]. 北京航空航天大学学报, 2020, 46(10): 1966-1972.LI L, REN Y, CHEN X C, et al. Design of MSCSG control system based on ADRC and RBF neural network[J]. Journal of Beijing University of Aeronautics and Astronautics, 2020, 46(10): 1966-1972(in Chinese). [21] REN Y, LI L, WANG W J, et al. Magnetically suspended control sensitive gyroscope rotor high-precision deflection decoupling method using quantum neural network and fractional-order terminal sliding mode control[J]. Fractal and Fractional, 2024, 8(2): 120. [22] LI L, REN Y, WANG W J, et al. Spacecraft attitude measurement and control integration using a novel configuration of variable speed magnetically suspended control and sensing gyroscope[J]. IEEE Sensors Journal, 2023, 23(9): 9359-9369. [23] D’ELEUTERIO G M T, HUGHES P C. Dynamics of gyroelastic continua[J]. Journal of Applied Mechanics, 1984, 51(2): 415-422. [24] 陈佳晶, 刘东. 反Hermite矩阵的若干性质[J]. 湖州师范学院学报, 2009, 31(2): 7-10.CHEN J J, LIU D. Some properties of skew Hermite matrices[J]. Journal of Huzhou Teachers College, 2009, 31(2): 7-10(in Chinese). [25] 沙成满, 李岩, 杨冬梅. 基于HJI微分不等式的非线性不确定奇异系统鲁棒镇定[J]. 东北大学学报(自然科学版), 2011, 32(12): 1680-1683.SHA C M, LI Y, YANG D M. Robust stabilization for a class of uncertain nonlinear singular systems based on HJI differential inequality[J]. Journal of Northeastern University (Natural Science), 2011, 32(12): 1680-1683(in Chinese). -
