Design of multiple-input/multiple-output control law for active flutter suppression of flying-wing aircraft
-
摘要:
针对飞翼布局飞机刚体模态与弹性模态耦合严重，体自由度颤振问题突出的特点，提出一种基于鲁棒控制理论的飞翼布局飞机体自由度颤振主动抑制控制律设计方法。该控制律设计方法将受控对象所受干扰及建模过程中存在的不确定参数统一视为 “未知扰动”，通过分析其输入/输出关系对其进行状态估计，最后，综合给出反馈控制律。为验证所提控制律的颤振抑制效果，以一飞翼布局无人机标模为分析对象，分别以机身内侧2副翼舵面作为控制输入，飞机刚体俯仰速度和翼尖运动速度为反馈信号来设计控制器。对闭环系统
V -g 曲线、闭环时域状态方程等进行了数值仿真，结果表明：该控制律设计方法能有效提高飞机颤振临界速度。-
关键词:
- 气动弹性 /
- 飞翼布局飞机 /
- 颤振主动抑制 /
- 体自由度颤振 /
- MIMO输出反馈控制器
Abstract:In this paper, a multiple-input/multiple-output control law design method for active flutter suppression of flying-wing aircraft is proposed. The input/output relationship of the plant is used to estimate and adjust the “unknown perturbation” caused by the uncertain factors of the controlled plant. The output feedback control law is then designed. In order to validate the effectiveness of the proposed control law on flutter suppression, a high aspect ratio flying-wing layout aircraft was chosen as the research object of this paper. For the controller synthesis, the inboard ailerons served as the control surfaces, and the rigid-body pitch rate combined with the wing tip motion velocity provided the feedback. A high aspect ratio flying-wing layout aircraft was selected as the research object for this paper in order to verify the efficacy of the suggested control law on flutter suppression. The two aileron rudder surfaces on the inside of the fuselage were used as control inputs, and the rigid body pitch speed and wing tip motion speed were used as feedback signals to design the control input. The relation between velocity and damping of the closed-loop system and the closed-loop time-domain state equation is carried out. The results show that the control law design method can effectively improve the critical flutter velocity of the aircraft.
-
表 1 模型主要几何尺寸
Table 1. Principal geometric dimensions of the model
展长b/m 机身长度L/m 展弦比 后掠角λ/(°) 翼根弦长 $ {c}_{\text{root}} $/m 3.05 0.85 10.2 22 0.299
下载: 导出CSV
表 2 模态参数
Table 2. Modal parameters
模态阶数 频率/Hz 模态振型 7 5.377 一阶对称弯曲 8 9.471 一阶反对称弯曲 9 12.783 一阶反对称扭转 10 14.411 一阶对称扭转 11 19.345 二阶对称弯曲 12 27.260 二阶反对称扭转 13 30.660 二阶反对称弯曲 14 31.654 二阶对称扭转
下载: 导出CSV
表 3 各阶模态对应特征向量
Table 3. Feature vectors corresponding to each mode
模态阶数 频率/Hz 模态振型 特征向量 3 0 刚体沉浮 0.054−0.048i 4 0 刚体俯仰 1.00 7 5.377 一阶对称弯曲 −0.58+0.30i 10 14.411 一阶对称扭转 0.036−0.013i 11 19.345 二阶对称弯曲 0.021−0.004i
下载: 导出CSV
-
[1] 黄锐, 胡海岩. 飞行器非线性气动伺服弹性力学[J]. 力学进展, 2021, 51(3): 428-466.HUANG R, HU H Y. Nonlinear aeroservoelasticity of aircraft[J]. Advances in Mechanics, 2021, 51(3): 428-466(in Chinese). [2] PENDLETON E W, BESSETTE D, FIELD P B, et al. Active aeroelastic wing flight research program: Technical program and model analytical development[J]. Journal of Aircraft, 2000, 37(4): 554-561. [3] ZHANG R, SINGH S N. Adaptive output feedback control of an aeroelastic system with unstructured uncertainties[J]. Journal of Guidance, Control, and Dynamics, 2001, 24(3): 502-509. [4] BEHAL A, RAO V M, MARZOCCA P, et al. Adaptive control for a nonlinear wing section with multiple flaps[J]. Journal of Guidance, Control, and Dynamics, 2006, 29(3): 744-749. [5] ZENG J, KUKREJA S L, MOULIN B. Experimental model-based aeroelastic control for flutter suppression and gust-load alleviation[J]. Journal of Guidance, Control, and Dynamics, 2012, 35(5): 1377-1390. [6] LIVNE E. Aircraft active flutter suppression: state of the art and technology maturation needs[J]. Journal of Aircraft, 2017, 55(1): 410-452. [7] LIBRESCU L, NA S, QIN Z M, et al. Active aeroelastic control of aircraft composite wings impacted by explosive blasts[J]. Journal of Sound and Vibration, 2008, 318(1-2): 74-92. [8] CAVAGNA L, RICCI S, SCOTTI A. Active aeroelastic control over a four control surface wing model[J]. Aerospace Science and Technology, 2009, 13(7): 374-382. [9] 杨发友, 顾仲权. 飞机机翼颤振自适应抑制研究[J]. 南京航空航天大学学报, 2004, 36(6): 708-712.YANG F Y, GU Z Q. Adaptive flutter suppression for aircraft wing[J]. Journal of Nanjing University of Aeronautics & Astronautics, 2004, 36(6): 708-712(in Chinese). [10] 宋晨, 吴志刚, 杨超. 基于PID控制器的颤振主动抑制控制律设计[C]//第十一届全国空气弹性学术交流会论文集. 昆明: 中国空气动力学会, 2009: 230-235.SONG C, WU Z G, YANG C. Design of active flutter suppression control law based on PID controller[C]//Proceedings of the 11th National Conference on Aeroelasticity. Kunming: CARS, 2009: 230-235. [11] 张子健, 徐敏, 曾晓彬, 等. LQG/LTR鲁棒控制器在机翼主动颤振抑制中的应用[J]. 西北工业大学学报, 2009, 27(2): 190-194.ZHANG Z J, XU M, ZENG X B, et al. Applying LQG/LTR theory to designing robust controller for active flutter suppression[J]. Journal of Northwestern Polytechnical University, 2009, 27(2): 190-194(in Chinese). [12] 张子健, 徐敏, 陈士橹. 机翼颤振的混合灵敏度H∞鲁棒控制器设计[J]. 计算力学学报, 2010, 27(4): 661-666.ZHANG Z J, XU M, CHEN S L. Mixed sensitivity H∞ controller designing for active flutter suppression[J]. Chinese Journal of Computational Mechanics, 2010, 27(4): 661-666(in Chinese). [13] 刘祥, 孙秦. 一种弹性机翼的颤振主动抑制与阵风减缓方法[J]. 西北工业大学学报, 2015, 33(5): 804-810.LIU X, SUN Q. A robust active flutter suppression and gust alleviation method for flexible wing[J]. Journal of Northwestern Polytechnical University, 2015, 33(5): 804-810(in Chinese). [14] 郑晓珂, 唐炜, 王立博, 等. 颤振主动抑制的LPV控制设计[J]. 振动工程学报, 2018, 31(3): 411-416.ZHENG X K, TANG W, WANG L B, et al. LPV control design for active flutter suppression[J]. Journal of Vibration Engineering, 2018, 31(3): 411-416(in Chinese). [15] 于明礼, 文浩, 胡海岩. 二维翼段颤振的H∞控制[J]. 振动工程学报, 2006, 19(3): 326-330.YU M L, WEN H, HU H Y. Active flutter suppression of a two-dimensional airfoil using H∞ synthesis[J]. Journal of Vibration Engineering, 2006, 19(3): 326-330(in Chinese). [16] 于明礼, 文浩, 胡海岩, 等. 二维翼段颤振的μ控制[J]. 航空学报, 2007, 28(2): 340-343.YU M L, WEN H, HU H Y, et al. Active flutter suppression of a two-dimensional airfoil section using μ synthesis[J]. Acta Aeronautica et Astronautica Sinica, 2007, 28(2): 340-343(in Chinese). [17] HUANG R, ZHAO Y H, HU H Y. Wind-tunnel tests for active flutter control and closed-loop flutter identification[J]. AIAA Journal, 2016, 54(7): 2089-2099. [18] 李星. MIMO几何非线性机翼气动伺服弹性分析与试验[D]. 大连: 大连理工大学, 2020.LI X. Aeroservoealstic analysis and experiment of MIMO wings with geometrically nonlinear wings[D]. Dalian: Dalian University of Technology, 2020(in Chinese). [19] HASHEMI K E, PAK C G, AKELLA M R. Akella, Delta adaptive flexible motion control for the X-56A aircraft[C]//Proceedings of the AIAA Atmospheric Flight Mechanics Conference. Reston: AIAA, 2015: 2244. [20] 杨超, 宋晨, 吴志刚, 等. 多控制面飞机的全机颤振主动抑制设计[J]. 航空学报, 2010, 31(8): 1501-1508.YANG C, SONG C, WU Z G, et al. Active flutter suppression of airplane configuration with multiple control surfaces[J]. Acta Aeronautica et Astronautica Sinica, 2010, 31(8): 1501-1508(in Chinese). [21] 沐旭升, 邹奇彤, 黄锐, 等. 体自由度颤振主动抑制的多输入/多输出自抗扰控制律设计[J]. 振动工程学报, 2020, 33(5): 910-920.MU X S, ZOU Q T, HUANG R, et al. Design of multiple-input/multiple-output active disturbance rejection controller for body-freedom flutter suppression[J]. Journal of Vibration Engineering, 2020, 33(5): 910-920(in Chinese). [22] BURNETT E, ATKINSON C, BERANEK J, et al. NDOF simulation model for flight control development with flight test correlation[C]// Proceedings of the AIAA Modeling and Simulation Technologies Conference. Reston: AIAA, 2010: 7780. [23] 赵永辉. 气动弹性力学与控制[M]. 北京: 科学出版社, 2007.ZHAO Y H. Aeroelastic mechanics and control[M]. Beijing: Science Press, 2007(in Chinese). -
