基于舵面配平的飞机续航飞行航迹优化方法

刘帆,  王立新,  蔡为民

downloadPDF
文章导航 > 北京航空航天大学学报  > 2016 >  42(1): 79-86.
刘帆, 王立新, 蔡为民等 . 基于舵面配平的飞机续航飞行航迹优化方法[J]. 北京航空航天大学学报, 2016, 42(1): 79-86. doi: 10.13700/j.bh.1001-5965.2015.0067
引用本文: 刘帆, 王立新, 蔡为民等 . 基于舵面配平的飞机续航飞行航迹优化方法[J]. 北京航空航天大学学报, 2016, 42(1): 79-86. doi: 10.13700/j.bh.1001-5965.2015.0067
shu
LIU Fan, WANG Lixin, CAI Weiminet al. Trajectory optimization method of aircraft endurance flight based upon control surface trimming[J]. Journal of Beijing University of Aeronautics and Astronautics, 2016, 42(1): 79-86. doi: 10.13700/j.bh.1001-5965.2015.0067(in Chinese)
Citation: LIU Fan, WANG Lixin, CAI Weiminet al. Trajectory optimization method of aircraft endurance flight based upon control surface trimming[J]. Journal of Beijing University of Aeronautics and Astronautics, 2016, 42(1): 79-86. doi: 10.13700/j.bh.1001-5965.2015.0067(in Chinese)
shu

基于舵面配平的飞机续航飞行航迹优化方法

doi: 10.13700/j.bh.1001-5965.2015.0067
  • 1.

    北京航空航天大学航空科学与工程学院, 北京 100083

  • 2. 中航工业沈阳飞机设计研究所, 沈阳 110035

详细信息
    作者简介:

    刘帆男,博士研究生。主要研究方向:飞行动力学与控制。Tel.:010-82338821E-mail:LF1224@163.com;王立新男,博士,教授。主要研究方向:飞行器设计、飞行动力学与控制。Tel.:010-82338821E-mail:wlx_c818@163.com

    通讯作者:

    王立新,Tel.:010-82338821E-mail:wlx_c818@163.com

  • 中图分类号: V221

Trajectory optimization method of aircraft endurance flight based upon control surface trimming

  • 1.

    School of Aeronautic Science and Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100083, China

  • 2. Shenyang Aircraft Design Institute of Aviation Industry Corporation of China, Shenyang 110035, China

    摘要
  • 摘要: 舵面偏转除了能够提供保证飞机稳定飞行的配平力矩,还将改变飞机的升阻比,从而影响其续航性能。在基于飞机质点假设的传统航迹优化方法的基础上,研究了飞机的升阻特性对其续航性能的影响:在上升段、巡航段及下降段前期增大升阻比,在下降段后期减小升阻比,有利于提高飞机的续航性能;提出了基于舵面配平的续航飞行航迹优化方法,以获得更接近于发挥飞机实际潜力的最优航迹与最大航程。对于多操纵面布局飞机,通过该方法能够确定其最优舵面组合配平规律。算例飞机的优化结果表明:相比单一舵面配平,最优舵面组合配平能够使算例飞机的总航程最大提高7.5%。



    Abstract: Besides providing balancing moment for stable flight, control surface deflection will change the lift-drag ratio of the airplane, which affects the endurance performance of the airplane. Based on the traditional flight trajectory optimization which assumes that the airplane is a particle, the effects of lift-drag characteristic on aircraft endurance performance are analyzed. Increasing lift-drag ratio at climb segment, cruise segment and earlier descent segment, and decreasing lift-drag ratio at later descent segment will improve the endurance performance of the airplane. In order to obtain the optimum flight trajectory and range closer to the actual potential of airplane, a trajectory optimization method of aircraft endurance flight based upon control surface trimming is proposed. Through this method, the optimum combined trimming mode of control surfaces can be obtained for multi-control surface airplane. The optimization result of a type of aircraft indicates that, compared to single trimming modes of control surface, the optimum combined trimming mode increases the total range by 7.5% at most for the example airplane.



    • HTML全文
    • 参考文献(16)
  • [1] HUANG G Q,LU Y P,NAN Y.A survey of numerical algorithms for trajectory optimization of flight vehicles[J].Science China Technological Sciences,2012,55(9):2538-2560.
    [2] RIVAS D,FRANCO A,VALENZUELA A.Optimization of unpowered descents for commercial aircraft:AIAA-2011-7019[R].Reston:AIAA,2011.
    [3] CHERN J S,LIU Y C,CHEN C S.Investigation of maximum range cruise flight for B787:AIAA-2010-7809[R].Reston:AIAA,2010.
    [4] SHAPIRA I,BEN-ASHER J.Range maximization for emergency landing after engine cutoff[J].Journal of Aircraft,2005,42(5):1296-1306.
    [5] LI X,NAIR P B,ZHANG Z G.Aircraft robust trajectory optimization using nonintrusive polynomial chaos[J].Journal of Aircraft,2014,51(5):1592-1603.
    [6] NG H K,SRIDHAR B,GRABBE S.Optimizing aircraft trajectories with multiple cruise altitudes in the presence of winds[J].Journal of Aerospace Information Systems,2014,11(1):35-47.
    [7] 陈晓,王新民,周健.无人飞行器纵向剖面轨迹优化[J].控制理论与应用,2013,30(1):31-36. CHEN X,WANG X M,ZHOU J.Optimization of vertical profile trajectory for unmanned aerial vehicle[J].Control Theory & Applications,2013,30(1):31-36(in Chinese).
    [8] FLANZER T C,BOWER G C,KROO I M.Robust trajectory optimization for dynamic soaring:AIAA-2012-4603[R].Reston:AIAA,2012.
    [9] MUELLER R.Multi-objective optimization of an aircraft trajectory between cities using an inverse model approach:AIAA-2012-4489[R].Reston:AIAA,2012.
    [10] VALENZUELA A,RIVAS D,FRANCO A.Cruise optimization using trajectory patterns:AIAA-2010-9140[R].Reston:AIAA,2010.
    [11] SACHS G,LENZ J,HOLZAPFEL F.Trajectory optimization for maximizing the range of powered sailplanes with retractable propeller:AIAA-2009-5626[R].Reston:AIAA,2009.
    [12] 方振平,陈万春,张曙光.航空飞行器飞行动力学[M].北京:北京航空航天大学出版社,2005:26-30,34,43. FANG Z P,CHEN W C,ZHANG S G.Aircraft flight dynamics[M].Beijing:Beihang University Press,2005:26-30,34,43(in Chinese).
    [13] WANG G,HU Y,WU C,et al.Improving performance of flying wing UAV with propeller thrust involved trimming the pitching moment:AIAA-2013-4421[R].Reston:AIAA,2013.
    [14] 周堃,王立新.大型军用运输机的飞行航迹优化[J].北京航空航天大学学报,2010,36(6):654-658. ZHOU K,WANG L X.Vertical flight trajectory optmization of heavy military airlift aircraft[J].Journal of Beijing University of Aeronautics and Astronautics,2010,36(6):654-658(in Chinese).
    [15] WU S F,GUO S F.Optimum flight trajectory guidance based on total energy control of aircraft[J].Journal of Guidance,Control and Dynamics,1994,17(2):291-296.
    [16] CAVCAR A.Climb performance of piston-propeller airplane with cambered wing and variable propeller efficiency[J].Journal of Aircraft,2011,48(5):1701-1707.
